FusionServer 5288 V5 Rack Server

Parameter Description

Model

FusionServer 5288 V5

Form Factor

4U rack server

Processors

1 or 2 1st Generation Intel^® Xeon^® Scalable processors (3100/4100/5100/6100/8100 series), up to 205W

1 or 2 2nd Generation Intel^® Xeon^® Scalable processors (3200/4200/5200/6200/8200 series), up to 205W

Memory

24 DDR4 DIMM slots, 2933 MT/s; up to 12 Intel^® Optane™ PMem modules (100 series), 2666 MT/s

Internal Storage

Front:

• 24 x 3.5-inch SAS/SATA hard drives

Embedded:

• 4 x 3.5-inch SAS/SATA hard drives

Rear:

• 16 x 3.5-inch SAS/SATA hard drives

• 16 x 3.5-inch SAS/SATA hard drives + 4 x 2.5-inch SAS/SATA hard drives or NVMe SSDs

• 14 x 3.5-inch SAS/SATA hard drives (or 4 NVMe SSDs for the NVMe model) + 4 x 2.5-inch SAS/SATA hard drives or NVMe SSDs (this configuration does not support internal hard disk and I/O module 1)

Flash storage:

• Two M.2 SSDs

RAID

RAID 0, 1, 5, 50, 6, or 60; optional supercapacitor to protect cache data from power failures; RAID level migration, drive roaming, self-diagnosis, and web-based remote configuration

Network Ports

• LOM: 2 x 10 GE + 2 x GE ports

• Flexible NIC: 2 x GE, 4 x GE, 2 x 10 GE, or 1/2 x 56G FDR IB ports

PCIe Expansion

Up to 10 PCIe 3.0 slots, including 1 for a RAID controller card and 1 for a flexible NIC

Fan Modules

4 hot-swappable fan modules with optional N+1 redundancy

Power Supply

2 hot-swappable PSUs with optional 1+1 redundancy. Supported options include:

• 900W AC Platinum PSU

• 1,500W AC Platinum PSU

Management

• BMC integrates one dedicated management GE network port to provide comprehensive management features such as fault diagnosis, automated O&M, and hardware security hardening

• BMC supports standard interfaces such as Redfish, SNMP, and IPMI 2.0; provides a remote management interface based on HTML5/VNC KVM; supports CD-free deployment and the Agentless feature, simplifying management

• (Optional) Configured with the FusionDirector management software to provide advanced management features such as stateless computing, batch OS deployment, and automated firmware upgrade, enabling smart and automatic entire-lifecycle management

Certifications

CE, UL, FCC, CCC, and RoHS

Installation Suite

L-shaped guide rails, adjustable guide rails, and holding rails

Dimensions (H x W x D)

175 mm x 447 mm x 748 mm (6.89 in. x 17.60 in. x 29.45 in.)

Operating Temperature

5°C to 40°C (41°F to 104°F) (ASHRAE Class A3 compliant)
