XFusion New-Generation 2288 V7 2U 2-Socket Rack Server

2U rack server

1 or 2 x 4th or 5th Gen Intel^® Xeon^® Scalable processors with TDP up to 225 W per processor

Emmitsburg PCH

16 x DDR5 DIMMs, delivering up to 4800 MT/s speed

Supports hot-swappable drives in the following configuration options:

• 8 to 31 x 2.5ʺ SAS/SATA/SSD drives

• 10 to 14 x 3.5ʺ SAS/SATA drives

• 4 x NVMe SSDs

• Up to 31 x 2.5ʺ drives

Supports flash storage:

• 2 x M.2 SSDs

Supports RAID 0, 1, 10, 1E, 5, 50, 6, or 60, optional supercapacitor for cache data power failure protection, RAID level migration, drive roaming, self-diagnosis, and remote web-based configuration

Expansion capability for multiple types of networks

Supports OCP 3.0 NICs. One FlexIO card slot supports one OCP 3.0 NIC, which can be configured as required

Up to 8 x PCIe slots

1 x FlexIO expansion slot dedicated for OCP 3.0, 1 x expansion slot dedicated for the RAID controller card, and 6 x standard PCIe expansion slots

Up to 4 x 75 W half-height half-length GPU accelerator cards

4 x hot-swappable counter-rotating fans in N+1 redundancy

900 W/1200 W/1500 W/2000 W/3000 W Platinum/Titanium hot-swappable PSUs in 1+1 redundancy

The iBMC chip integrates one dedicated management GE network port, providing comprehensive management features such as fault diagnosis, automatic O&M, and hardware security hardening

• The iBMC supports standard interfaces such as Redfish, SNMP, and IPMI 2.0, provides a remote management interface based on HTML5/VNC KVM, and supports out-of-band management functions such as monitoring, diagnosis, configuration, Agentless, and remote control for simplified management

• It is optional to configure the FusionDirector management software that provides advanced management features such as five intelligent technologies and realizes intelligent, automated, visualized, and refined management throughout the lifecycle

FusionOS, Microsoft Windows Server, SUSE Linux Enterprise Server, VMware ESXi, Red Hat Enterprise Linux, CentOS, Oracle, Ubuntu, Debian, and openEuler . For more, click here

Power-on password, administrator password, Trusted Platform Module (TPM) 2.0, security bezel, secure boot, and chassis intrusion detection

5ºC to 40ºC (41ºF to 104ºF), compliant with ASHRAE Classes A1, A2, A3, and A4

CE, UL, CCC, FCC, VCCI, and RoHS

L-shaped guide rails, adjustable guide rails, and holding rails

Chassis with 3.5ʺ drives: 86.1 mm x 447 mm x 798 mm (3.39 in. x 17.60 in. x 31.42 in.)

Chassis with 2.5ʺ drives: 86.1 mm x 447 mm x 798 mm (3.39 in. x 17.60 in. x 31.42 in.)
